| Max. Temperature | 1700F
926C | | Amps | 30 | | Phase | 1 | | Watts | 7200 | | Nema | 6-30R | | Breaker Size | 40 | | Circuit Copper Wire Size | 8 gauge | | TUV tested to CSA and UL Standard 499 | Y | | CE | Y | | IMPORTANT: Some areas such as Canada and Europe require a lid or door safety switch on kilns.
| | Control Type |
Sentry Digital 12-key Non-Ceramic
| | Voltage | 240 | | Hertz | 60 | | Nema Details | |
| | Disclaimer: The specifications above assume that the kiln will be plugged into a dedicated circuit. Local electric codes supersede our recommendations. The pricing and electrical specifications for the above products reflect their design for use in the United States. The International versions of most models will have variations in electrical specifications and price due to consumer safety requirements or electrical regulations. | | | Kiln Type | Top Loading Square | | Sides | 4 | | Understanding Chamber Measurements |
| | Chamber Volume | 3.64 CU.FT.
103.07 litres | | Chamber Length | 22.00 IN
559 mm | | Chamber Width | 22.00 IN
559 mm | | Chamber Depth | 13.00 IN
330 mm | |
The Outer Size of the Kiln and the Shipping Size: Width = Left to Right; Depth = Front to Back; Height = Top to Bottom
| | Outer Size | 32.00W x 37.00D x 26.00H Inches
813W x 940D x 660H mm | | Ship Size | 42.00W x 37.00D x 35.00H Inches
1067W x 940D x 889H mm | | Ship Weight | 320.00 Lbs.
145.15 Kg. | | Ship Method & Notations Important Shipping Information | This Kiln Ships Via Truck | | | | | | | | Part Number | 7761141EGP * Base Model | |
Recommended furniture kit for the Paragon Pearl-22 and equivalent sized kilns. Included:
1 - C-20 Shelf (20” square x 5/8”)
4 – 1/2” long, 1” wide Square Posts
1 lb. Bag Glass Separator
Paragon kilns are warranted to the original purchaser by Paragon Industries, L.P. (herein Paragon), subject to the listed exclusions below, to be free of defects in workmanship for the periods specified below. The warranty period begins from the date of shipment from the Paragon factory unless the date of the original purchase from an authorized Paragon distributor or dealer can be established.
Full Warranty Details
