Paragon Knife Oven-KM14T Pro Series 2-Zone

(No reviews yet) Write a Review
MSRP: $4,200.00
$3,780.00
(You save $420.00 )
SKU:
Paragon-KM14T-Pro
Availability:
Built To Order - 3-5 Weeks
Weight:
128.00 LBS
Shipping:
Calculated at Checkout

Product Overview

Paragon KM14 Pro 2 Zone – 14" Multizone Knife Heat Treating Furnace with Ceramic Fiber Interior

The Paragon KM14 Pro 2 Zone is a fast, durable heat treating kiln designed specifically for smaller knives and bladesmithing projects. Featuring a 14-inch deep ceramic fiber firing chamber, this professional-grade furnace heats quickly, reaching 1500°F in minutes, making it ideal for precise heat treating of tool steels and alloys.


Key Features:

  • Advanced Ceramic Fiber Chamber: Provides rapid heating and cooling with 2.5” thick space-age insulation for energy efficiency and temperature stability.

  • Long-Lasting Wavy Elements: Surface-mounted on chamber walls for fast heat dissipation and extended element life.

  • Solid-State Relay: Silent and durable operation with no moving parts, mounted on an aluminum heat sink for cool, reliable performance. Includes a secondary safety relay for extra protection.

  • Guillotine Door: Easy, one-handed upward lift keeps hot surfaces away from the user and ensures years of reliable service thanks to a heavy-duty spring mechanism.

  • Door Safety Switch: Automatically cuts power to heating elements when the door is opened, while the controller continues to display temperature readout.

  • Two High-Precision Thermocouples: ¼” Type-K, 14-gauge, special-limit wire with exposed tips provide fast, accurate temperature sensing and consistent heating.

  • Solid Construction: Includes a built-in stand that safely lifts the kiln off your work surface, and protects wiring inside the kiln’s rugged case—perfect for demanding workshop environments.

  • Custom Paint Options: Choose from a variety of paint colors at no additional cost; standard finish is a sleek deep black.


Optional Accessories:

  • Gas Injection Flow Meter: Helps prevent scaling during heat treating by injecting inert gas such as argon to displace oxygen inside the chamber. Available as an add-on or factory-installed option.


Specifications:

  • Max Temperature: 2350°F (1287°C)

  • Amperage: 20 Amps

  • Voltage: 240V, Single Phase

  • Wattage: 4840 Watts

  • NEMA Receptacle: 6-30R

  • Chamber Volume: 0.56 cubic feet (15.86 liters)

  • Chamber Dimensions: 13.25" W x 14" D x 5.25" H

  • Outer Dimensions: 20.5" W x 28" D x 18" H

  • Shipping Weight: 128 lbs

  • Doorway Clearance: 20.5"


The Paragon KM14 Pro 2 Zone kiln is a reliable, precision heat treating solution for bladesmiths seeking fast, even heating with advanced safety features and robust construction. Whether for hobbyists or professionals, it delivers consistent results for a wide range of smaller blade projects.

Specifications

Max. Temperature

2350F
1287C

Amps

15

Phase

1

Watts

3360

Nema

6-20R

Breaker Size

20

Circuit Copper Wire Size

12 gauge

TUV tested to CSA and UL Standard 499

N

CE

Y

Control Type


Sentinel Touch Screen

Voltage

240

Hertz

60

Nema Details







Disclaimer: The specifications above assume that the kiln will be plugged into a dedicated circuit. Local electric codes supersede our recommendations.

The pricing and electrical specifications for the above products reflect their design for use in the United States. The International versions of most models will have variations in electrical specifications and price due to consumer safety requirements or electrical regulations.



Kiln Type

Front Loading Square

Sides

4

Understanding Chamber Measurements

Chamber Volume

0.23 CU.FT.
6.51 litres

Chamber Width

6.50 IN
165 mm

Chamber Depth

14.00 IN
457 mm

Chamber Height

5.25 IN
133 mm


The Outer Size of the Kiln and the Shipping Size: Width = Left to Right; Depth = Front to Back; Height = Top to Bottom

Outer Size

14.50W x 28.00D x 18.00H Inches
368W x 457D x 457H mm

Ship Size

26.00W x 31.00D x 27.00H Inches
660W x 686D x 686H mm

Ship Weight

216.00 Lbs.
97.97 Kg.

Doorway Clearance Needed

15.00 Inches
381.00 mm

Ship Method & Notations



This Kiln Ships Via Truck









Part Number

S1726
* Base Model

Product Specifications

Warranty Information

Paragon kilns are warranted to the original purchaser by Paragon Industries, L.P. (herein Paragon), subject to the listed exclusions below, to be free of defects in workmanship for the periods specified below. The warranty period begins from the date of shipment from the Paragon factory unless the date of the original purchase from an authorized Paragon distributor or dealer can be established.

Full Warranty Details
