Paragon Fiber Fuse 16

Product Overview

Max. Temperature	1700F 926C
Amps	15
Phase	1
Watts	1800
Nema	5-15R
Breaker Size	20
Circuit Copper Wire Size	12 gauge
TUV tested to CSA and UL Standard 499	Y
CE	N
Control Type	Sentry Xpress 4.0 Digital 3-Key
Voltage	120
Hertz	60
Nema Details

Disclaimer: The specifications above assume that the kiln will be plugged into a dedicated circuit. Local electric codes supersede our recommendations. The pricing and electrical specifications for the above products reflect their design for use in the United States. The International versions of most models will have variations in electrical specifications and price due to consumer safety requirements or electrical regulations.

Kiln Type	Top Loading Square
Sides	4
Understanding Chamber Measurements
Chamber Volume	0.88 CU.FT. 24.92 litres
Chamber Length	16.00 IN 406 mm
Chamber Width	16.00 IN 406 mm
Chamber Depth	6.00 IN 152 mm
The Outer Size of the Kiln and the Shipping Size: Width = Left to Right; Depth = Front to Back; Height = Top to Bottom
Outer Size	30.00W x 21.00D x 13.00H Inches 762W x 533D x 330H mm
Ship Size	31.00W x 37.00D x 21.00H Inches 787W x 940D x 533H mm
Ship Weight	100.00 Lbs. 45.36 Kg.
Doorway Clearance Needed	20.00 Inches 508.00 mm
Ship Method & Notations Important Shipping Information	This Kiln Ships Via Truck


Part Number	S1647-3 * Base Model

Recommended furniture kit for the Paragon CS-16D, CS-16S, Fusion-16, and equivalent sized kilns.

Included:

1 – 14 1/2” x 14 1/2” x 5/8” Square Shelf

4 – 1/2” long, 1” wide Square Posts

1 lb. Bag Glass Separator

Product Specifications

Warranty Information

Paragon kilns are warranted to the original purchaser by Paragon Industries, L.P. (herein Paragon), subject to the listed exclusions below, to be free of defects in workmanship for the periods specified below. The warranty period begins from the date of shipment from the Paragon factory unless the date of the original purchase from an authorized Paragon distributor or dealer can be established.

Full Warranty Details
