Paragon W14

Product Overview

W-14-4 Digital Jewelry Kiln

The W-14-4 is made of durable insulating firebrick. The digital controller saves time, makes casting more reliable, and gives consistently repeatable results. The 12-key Sentry controller has 3 built-in, easy-to-use programs: EL wax elimination, 5 hour burnout, and 12 hour burnout. You can also enter your own programs with up to 20 segments for your exact needs. Includes an on-off toggle switch.

The W-14-4 has a heavy-gauge stainless steel case to resist corrosion. Heating elements are recessed to protect the element, yet the element is still accessible for easy replacement. This furnace also includes two top vents with ceramic plugs for lost wax burnout. A spring door latch tightly seals the door while permitting easy opening with one hand for removal of hot flasks.

Thermocouple with “special limit” wire

The thermocouple senses temperature inside the kiln. It is the small rod that extends into the firing chamber. The ¼” wide Type-K, 14-gauge, exposed-tip thermocouple is made with special-limit wire for superior accuracy. The exposed tip gives the controller a fast response time for even temperatures during holds. The thermocouple is made in America to our exacting standards.

Designed for production

Paragon’s warranty is not affected by frequency of use. Fire your new kiln every day if you want, even in commercial settings. That will have no effect on the warranty period.

Max. Temperature	2000F 1093C
Amps	16
Phase	1
Watts	3750
Nema	6-20R
Breaker Size	20
Circuit Copper Wire Size	12 gauge
TUV tested to CSA and UL Standard 499	N
CE	N
IMPORTANT: Some areas such as Canada and Europe require a lid or door safety switch on kilns.
Control Type	Sentry Digital 12-key Non-Ceramic
Voltage	220
Hertz	60
Nema Details

Disclaimer: The specifications above assume that the kiln will be plugged into a dedicated circuit. Local electric codes supersede our recommendations. The pricing and electrical specifications for the above products reflect their design for use in the United States. The International versions of most models will have variations in electrical specifications and price due to consumer safety requirements or electrical regulations.

Kiln Type	Front Loading Square
Sides	4
Understanding Chamber Measurements
Chamber Volume	1.59 CU.FT. 45.02 litres
Chamber Width	14.00 IN 356 mm
Chamber Depth	14.00 IN 356 mm
Chamber Height	14.00 IN 356 mm
The Outer Size of the Kiln and the Shipping Size: Width = Left to Right; Depth = Front to Back; Height = Top to Bottom
Outer Size	19.00W x 22.00D x 27.00H Inches 483W x 559D x 686H mm
Ship Size	31.00W x 31.00D x 39.00H Inches 787W x 787D x 991H mm
Ship Weight	240.00 Lbs. 108.86 Kg.
Ship Method & Notations Important Shipping Information	This Kiln Ships Via Truck


Part Number	W14-4 * Base Model

WAX TRAY AND GRATE, W13/W14, 12.5" x 12.5". Leave the heavy-duty grate in the kiln throughout the firing. Remove the wax tray at 300F/148C without disturbing the molds on the grate. The grate is carbon steel, and the pan is stainless steel.

Product Specifications

Warranty Information

Paragon kilns are warranted to the original purchaser by Paragon Industries, L.P. (herein Paragon), subject to the listed exclusions below, to be free of defects in workmanship for the periods specified below. The warranty period begins from the date of shipment from the Paragon factory unless the date of the original purchase from an authorized Paragon distributor or dealer can be established.

Full Warranty Details
