Paragon Kiln- CT61109/Max 119

Product Overview

Paragon CT61109

NEW! SSR (Solid State Relays) with mechanical backups.
Sentinel TouchXPress Touch Screen Controller
Large enough to fire a 10” plate
3” Firebrick Walls
Extra 2” insulation between the firebricks and the stainless steel case (4.5” thick walls)
3” Firebrick Lid
4.5” Firebrick Bottom
Lock-in lid support with positive catch
Coated lid & rim of firebrick
Full-formed galvanized steel base
Heavy-Duty Elements
Easy-access Switch Cover
Cold rolled stainless jacket
14-gauge thermocouple with special limit wire
Take advantage of the heat that radiates from the kiln. Load greenware on the lower shelf. The heat from the kiln will dry the ware to prepare it for the next firing. Save the time and electrical expense of drying the ware inside the kiln.

Assemble the stand with simple tools. The stand slides together with interlocking components that assemble with one size of bolt.

From China Painting, Decals, and Dolls to Glass Casting and Fusing... this little kiln can do it all!

Most impressively, with a 3" thick brick wall and a temperature rating of 2300°F, this heavily insulated kiln can fire ceramics on a 120 volt, 20 amp outlet! This is a kiln you will never outgrow. If you later buy a larger kiln, continue to use it for testing or small projects. Or, perfect a new design in the small kiln before running production quantities in the large kiln. A small test kiln is invaluable in solving ceramic glaze problems and perfecting difficult glazes such as

Heavily insulated

The walls are 4 1/2” thick! The 2 1/2” thick firebricks are backed with an extra 2” of block insulation between the firebricks and the stainless steel case. The lid is 3” thick, and the bottom is 4 1/2” thick.

Max. Temperature	2300F 1259C
Amps	18
Phase	1
Watts	2160
Nema	5-20R
Breaker Size	20
Circuit Copper Wire Size	12 gauge
TUV tested to CSA and UL Standard 499	Y
CE	N
IMPORTANT: Some areas such as Canada and Europe require a lid or door safety switch on kilns.
Control Type	Genesis Mini Touch Screen
Voltage	120
Hertz	60
Nema Details

Disclaimer: The specifications above assume that the kiln will be plugged into a dedicated circuit. Local electric codes supersede our recommendations. The pricing and electrical specifications for the above products reflect their design for use in the United States. The International versions of most models will have variations in electrical specifications and price due to consumer safety requirements or electrical regulations.

Kiln Type	Top Loading Round
Sides	6
Understanding Chamber Measurements
Chamber Volume	0.56 CU.FT. 15.86 litres
Chamber Width	11.00 IN 279 mm
Chamber Depth	9.00 IN 229 mm
The Outer Size of the Kiln and the Shipping Size: Width = Left to Right; Depth = Front to Back; Height = Top to Bottom
Outer Size	22.00W x 24.00D x 32.50H Inches 559W x 610D x 826H mm The external kiln height is when on a 18" tall stand (not included).
Ship Size	30.00W x 30.00D x 28.00H Inches 762W x 762D x 711H mm
Ship Weight	121.00 Lbs. 54.89 Kg.
Doorway Clearance Needed	22.00 Inches 558.80 mm
Ship Method & Notations Important Shipping Information	This Kiln Ships Via Truck


Part Number	S1666 * Base Model

Recommended furniture kit for the Paragon Max 119, and equivalent sized kilns.

Included:

1 C-10 Hexagon Shelf (10” hexagon x 1/2”)

1 C-10H Hexagon Half Shelf (10” hexagon half shelf x 1/2”)

1" wide Square Posts, 3 each of - 1”, 2”, 3” lengths

1 lb. Bag Kiln Wash

Product Specifications

Warranty Information

Paragon kilns are warranted to the original purchaser by Paragon Industries, L.P. (herein Paragon), subject to the listed exclusions below, to be free of defects in workmanship for the periods specified below. The warranty period begins from the date of shipment from the Paragon factory unless the date of the original purchase from an authorized Paragon distributor or dealer can be established.
